Working height
6.5m
Platform Capacity
240kg
Gradeability
25%
DIMENSIONS
Max Working Height
6.5m (21'4") (Indoor) / 5.8m (19') (Outdoor)
[A] Max Platform Height
4.5m (14'9") (Indoor) / 3.8m (12'6") (Outdoor)
[B] Max Horizontal Extension
0.6m (23.6")
[C] Length-Stowed
1.42m (4'8")
[D] Width-Stowed
0.76m (2'6")
Height - stowed Rail Folded
1.67m (5'6")
[E] Height - stowed Rail Unfolded
1.97m (6'6")
Height - stowed Fixed Rail
1.97m (6'6")
[F] Wheelbase
1.11m (3'8")
Ground Clearance
(Pothole Guard Stowed)
61mm (2.4")
Ground Clearance
(Pothole Guard Deployed)
20mm (0.75")
Platform Dimensions(L×W×H)
1.34m×0.7m×1.1m (4'5"×2'4"×3'7")
PERFORMANCE
Platform Allowable Occupants
(Indoor/Outdoor)
2 persons (Indoor) / 1 person (Outdoor)
Platform capacity
240kg (529lbs)
Lift Extension Capacity
115kg (254lbs)
Drive Speed-Stowed
4km/h (2.5mph)
Drive Speed-Raised
0.8km/h (0.5mph)
Elevation Time(Unloaded)
20s~23s
Descent Time(Unloaded)
25s~27s
Gradeability
25%
Turning Radius
(Inside/Outside)
0.3m/1.35m (12"/4'5")
Tilt Rating
(Front to Back/Side to Side)
3°/1.5°
Tyres-solid
255×76mm (10x3")
POWER
Batteries
24V,120Ah (Lead acid battery)
Power Source
24V DC
Drive Mode
2WD×2WS
Charger Input
100~240V AC
Charger Output
15A
Hydraulic System Capacity
4L (0.9 UK gal / 1.05 US gal)
Weight(Indoor/Outdoor)
880kg (1,941lbs)
Weight(Indoor Only)
-
Standards Compliance
CE/ANSI/CSA/AS/EAC/KCS
