10T - 16T ED160BR-7

'Proudly representing Kobelco in North East Victoria and Southern NSW'

Excavator and dozer in one versatile machine.
Tier 4 Final compliant engine.
6-way power angle-tilt blade with single-level dozer control.
2YR/3,000HR Full Machine Warranty and 4YR/6,000HR Major Component Extended Warranty.

The ED160 Blade Runner has the power to doze and backfill in all recommended operating positions. With unforgettable comfort with a Grammer air suspension seat as standard and a 10-inch colour monitor. Excellent ground clearance ensures unhindered travel.

Includes Kobelco Geoscan Excavator Remote Monitoring System.

SPECIFICATIONS
Transport Dimensions
Length, Width & Height

8.55 x 2.59 x 2.82 m** (**600 mm shoe)

Operating Weight

17,000 kg with dozer

Refilling Capacities
Fuel Tank

186 L

Hydraulic Oil Tank

89.9 (190) L

Working Range
Max. Digging Depth

5.36 m

Max. Digging Reach

8.17 m

Engine
Rated Power Output

86 kW

Rated Torque

375 Nm

Breakout Force
Bucket Digging Force

105.4 kN

Arm Crowding Force

64.0 kN

Hydraulic System
Max. Pump Flow

2 x 142 L/min + 22, 67 L/min

Standard Auxiliary

N&B + Tilt Piping
