10T - 16T SK140LC-11

'Proudly representing Kobelco in North East Victoria and Southern NSW'

Productive mechanical power, operating speed, refined operator comfort and fuel efficiency.
Strong work performance, including a best in class drawbar pulling force of 141kN.
High-rated bucket digging force of 105.4kN.
2YR/3,000HR Full Machine Warranty and 4YR/6,000HR Major Component Extended Warranty.

The SK140 delivers greater efficiency and productivity with increased power and speed, along with uncompromising operator comfort and machine operability.

In the pursuit of producing unique and unbeatable machines that provide comfort and productivity without equal, KOBELCO continues to rise to the challenge. Easy transportability with a folding blade design, allowing for a 2590mm transport width.

The SK140LC-11 design includes a thoroughly modern and spacious cabin that features intuitive, easy-to-use operating controls and systems not unlike today’s premium automobiles. True ergonomic functionality combined with modern design has resulted in a cabin interior that is sleek and comfortable, built for simplicity and operator comfort. Includes Kobelco Geoscan Excavator Remote Monitoring System.

SPECIFICATIONS
Transport Dimensions
Length, Width & Height

7.8 x 2.69 x 3.14 m

Operating Weight

15,200kg with dozer

Refilling Capacities
Fuel Tank

289 L

Hydraulic Oil Tank

96.7 (180) L

Working Range
Max. Digging Depth

5.98 m

Max. Digging Reach

8.78 m

Engine
Rated Power Output

78.5 kW

Rated Torque

375 Nm

Breakout Force
Bucket Digging Force

105.4 kN (ISO 6015)

Arm Crowding Force

58.0 kN (ISO 6015)

Hydraulic System
Max. Pump Flow

2 x 130 L/min + 20, 50 L/min

Standard Auxiliary

N&B + Tilt Piping
