132 kw 175 hp 4-pole 1490 rpm 415v 315S/M frame IP66 AC Electric Motor WEG Model K62 W22 VSD

132 kw 175 hp 4-pole 1490 rpm 415 volt Foot Mount 315S/m frame IP66 Industrial AC Electric Motor WEG Model K62 W22 VSD

Category: AC Squirrel Cage Electric Motor
3-phase induction motor
Make: WEG
Model: K66 W22 VSD
YOM: 2020 (Made in Brazil)
Power: 132 KW (175 HP)
Speed: 4-pole (1490 rpm)
Rated Frequency: 50 hz
Rated Voltage: 415v
Mount: B3 Foot
Frame: 315S/M
Weight: 1095 kg
Inclusions: This unit is set up for VSD application if required (NDE Insulated endshield, plus earth brush fitted to shaft)

Total Length: 1276 mm (incl. shaft)
Total Width: 858 mm (incl. standard RHS to D.E. terminal box)... note: box can be LHS or Top Mount
Total Height: 750 mm
Feet Measurements: Across 'A' - 508 mm, Front to Back 'B' (2 holes) - 406 mm and 457 mm
Front hole to shaft 'C' - 216 mm
Centre shaft height - 315 mm
Shaft DIA - 85 mm
Shaft Length - 170 mm

Available QTY: 1
Condition: YOM 2020, unused and decommissioned critical spare. N/L test run & painted in motor workshop. Factory storage
exStock Seaford VIC Australia
Available for immediate despatch - Freight services available Australia-Wide on request
