2007 KOMATSU PC300-8 Excavator | 10440Hrs | For Sale

LOCATED IN CANNING VALE, WA.
$115,000 +GST

The PC300-8M0 incorporates a holistic, integrated design with a host of standard factory installed items to provide piece of mind and compliance with industry expectations.  It combines Dash 8 quality and performance with new fuel saving technology to further improve fuel efficiency, upgraded monitor / KOMTRAX functionality and high capacity air conditioning with increased cool down performance.

This 33+ tonne excavator includes the latest technology, ergonomics and features.  It is suited to large construction jobs requiring a combination of heavy lift, wide working range and high productivity.

Highly productive cycle times are achieved through optimum weight and power balance.


EQUIPMENT DETAILS
Year 2007
Make Komatsu
Model PC300


Performance
Operating Weight  33800kg
Swing speed 9.5 rpm
Bucket digging force (ISO)  23200 kgf
Arm crowd force (ISO) 17400 kgf
Digging depth maximum 7380 mm
Digging reach maximum 11100 mm
Maximum reach ground level 10920 mm
Horsepower, Gross SAE  194 kW
Horsepower, Net ISO 187 kW
Horsepower, Net SAE 1950 kW
Rated RPM 1950
Fan drive method Mechanical
Displacement (litre) 8.27
Number of cylinders 6

Dimensions
Overall length 11150 mm
Length on ground (transport) 5755 mm
Overall height (to top of boom) 3285 mm
Overall width 3190 mm
Overall height (to top of cab) 3145 mm
Ground clearance, counterweight 1185 mm
Ground clearance (minimum)   500 mm
Tail swing radius   3450 mm
Track length on ground     3700 mm
Track length 4625 mm
Track gauge   2590 mm
Width of crawler   3190 mm
Shoe width   600 mm
Grouser height   36 mm
Machine cab height   2585 mm
Machine cab width   3090 mm
Distance, swing center to rear end 3405 mm

Working Range
Max. digging height 10100 mm
Max. dumping height     7050 mm
Max. digging depth     7380 mm
Max. vertical wall digging depth   6400 mm
Max. digging depth of cut for 8 level       7180 mm
Max. digging reach   11100 mm
Max. digging reach at ground level 10920 mm
Min. swing radius   4430 mm
