28.5 kw 40 hp 1096 rpm 160 frame DC Electric Motor

28.5 kw 40 hp 1096 rpm 160 frame DC Electric Motor

Type: DC Electric Motor
Make: BBC Brown Boveri
Power: 28.5 kw (40 hp)
Base Speed: 1096 rpm
Armature Volts: 440 v
Armature Amps: 74
Field Volts: 220 v
Field Amps: 6.7
Mount: B3 Foot
Frame: 160
Shaft: 48 mm dia, 110 mm long
Centre shaft height: 160 mm
Total Motor Length: 1100 mm inc. shaft & tacho
Total Motor Width: 480 mm
Total Motor Height: 320 mm
Terminal box: RHS (Can be LHS)
Feet Measurements: 520 mm front to back, 255 mm across
Qty: 1
Condition: Fully Reconditioned
Available now
