3.8m Italian Panel Saw with Electric Rise, Fall & Tilt. In-Stock!

Wood Tech. Aus Owned and Operated. Local Parts and Service in 5 Locations. Download Brochure Now.


The Wood Tech Group brings in the highest quality brands from the top manufacturers for wood, stone, glass & composite materials from around the world.

The Fimal Concept 450ax automatic Panel Saw is in stock ready to be installed.

Saw unit with long shaft

The saw blade unit, with a long shaft, runs vertically along ground bars. Stability and lack of vibration are ensured by the considerable distance between the bearings and the long shaft.

Excellent quality and cutting finish

The sliding system adopted on the new carriage, with large diameter bearings that roll along tempered and ground prismatic tracks, provides excellent smoothness and ± 0.05 mm straight cutting along the whole carriage stroke.

Speed change

The speed change is very quick and easy because it can be simply executed through an opening that is above the working table.


SPECIFICATIONS

FIXED TABLE DIMENSIONS/HEIGHT: 1030x680/870mm
CARRIAGE DIMENSIONS: 3800x350mm
CUTTING WIDTH: 1300mm
MAX.DIAM. SAW BLADE/HOLE: 450/30mm
MOTOR POWER: 5.5KW
WEIGHT KG: 900kg

F.I.M.A.L is a deeply-established company in the “Marche” Region of Italy.

Known not only for its internal production division, which starts from primary aluminium and cast iron processing up to the assembly and testing of each machine, but also for their Italian Supply Network which guarantees high quality raw materials and components from Italy.

The Wood Tech Group provides machinery sales and service throughout Australia. We have showrooms for machine demonstrations in Melbourne, Sydney, Brisbane, Perth & Adelaide.

We provide sound professional advice and the best machinery solutions to help your business thrive. The Wood Tech Group also provides efficient and dependable after sales service.

Need a quote? or want more technical information about our machines? Or see them in action?

Please contact one of our teams in a state nearest you.
