30 kw 40 hp 4-pole 1480 rpm 415v Foot Mount D200L frame IP56 Mining TEFC AC Electric Motor Toshiba Model TSH01 Unused
Category: AC Squirrel Cage Electric Motor
3-phase induction motor
Make: Toshiba
Model: TSH01
YOM: 2019
Power: 30 kw (40 hp)
Speed: 4-pole (1480 rpm)
Rated frequency: 50 hz
Rated voltage: 415v
Mount: B3 Foot
Frame: 200L
Protection Rating:TEFC IP56 Mining
Insulation Class: H
Duty: S1
Weight: 318 kg
Critical Measurements:
Shaft DIA: 60 mm (by 110mm long)
Centre Shaft Height: 200 mm
Total Length: 760 mm (incl. shaft)
Total Width: 600 mm (incl. LHS to D.E. Terminal Box)
Total Height: 430 mm
Feet Measurements: Across 'A' - 305 mm, Front to Back 'B' - 318 mm
Front hole to shaft 'C' - 135 mm
Available QTY: 1
Condition: Unused (YOM 2019, decommissioned & crated critical spare - N/L test run & painted July 2023
exStock Seaford VIC 3198 Australia
Freight services Australia wide available upon request, immediate despatch
