40-315mm HDPE Drainage Welder - Ritmo Universal 315

The Italian-Made Ritmo Universal 315 V1 Drainage welding machine is suitable for welding Electrofusion fittings in HDPE from Ø 32 to Ø 315 mm.

Matrix Piping Systems also offers servicing, calibration and spare parts for Ritmo poly welding machinery. Our experienced team of service technicians can assist you with diagnosing and repairing any issues that may arise. Call us today to find out more!

Machine Composition:

- Low pressure HDPE Ø 32 ÷ 315 mm;
- PP-R from 20 ÷ 63 mm (optional cables)
- Graphic display
- Auto recognition of fittings
- Memory with 350 welding reports
- Report in PDF File
- Serial/USB connector (optional)
- Self-compensation of the current supplied
(according to the ambient temperature)
- Transport case
- Firmware upgradable via USB
- Carrying suitcase
- Welding cables * (A00, A01, A02, A03, A04, A00+)
- Welding extension cable
- Manual scraper
- Shoulder belt


Accessories Available on Request:

- serial/USB adapter (welding data transfer)
- welding cable A05

Technical features:

Materials: HDPE - low pressure, PP-R (ON REQUEST)
Working range: Ø 20 ÷ 315 mm
Power supply: 230 V single phase 50/60 Hz, 110 V single phase 50/60 Hz
Total absorbed power: 2470 W (230 V), 2700 W (110 V)
Outside temperature range: -10° ÷ 45° C
Temperature compensation: Automatic Electronic
Protection degree: IP 54
Dimensions machine: 255 x 180 x 110 mm (230 V), 330 x 270 x 220 mm (110 V )
Case dimensions: 220 x 450 x 180 mm (230 V), 410 x 290 x 485 mm (110 V)
Weight machine: 3,4 Kg (230 V), 19 Kg (110 V)
Weight machine and carrying case: 7,2 Kg (230 V)
