JLG 600AJ Articulating Boom Lift
Engine-Powered Boom Lift | 600 Series
Key Features:
Best reach envelope in its class
Optional articulating jib for accessing hard-to-reach places
Unmatched maneuverability for confined work areas
Quick Specs:
Platform Height (Elevated): 60 ft
Overall Width: 8 ft
Platform Capacity: 500 lb
Chassis:
Drive Speed: 2WD & 4WD – 4.25 mph (6.8 km/h)
Gradeability: 2WD – 30% | 4WD – 45%
Turning Radius (Inside): 2WS – 11'5" (3.48 m) | 4WS – 5'6" (1.68 m)
Turning Radius (Outside): 2WS – 17'8" (5.38 m) | 4WS – 11'8" (3.56 m)
Axle Oscillation: 8" (20 cm)
Tire Size: 14 x 17.5 | Tyre Type: Lug Tread
Dimensions:
Platform Size: 36" x 96" (0.91 m x 2.44 m)
Tailswing: Zero
Stowed Height: 8'4" (2.54 m)
Stowed Length: 28'11.5" (8.83 m)
Wheelbase: 8' (2.44 m)
Ground Clearance: 12" (30 cm)
Weight: 23,050 lb (10,455 kg)
Max. Ground Bearing Pressure: 75 psi (5.25 kg/cm²)
Power Source:
Dual Fuel Engine (GM Vortec 3000 MPFI): 82 hp (61 kW)
Diesel Engine (Deutz D2011L04 / Caterpillar 3044C): 65 hp / 63.3 hp (48 kW / 47.2 kW)
Fuel Tank Capacity: 30 gal (113.56 L)
Hydraulic Reservoir: 30.6 gal (115.83 L)
Auxiliary Power: 12V DC
Noise Level: 70 dBa at 7 meters
JLG Industries is dedicated to delivering top-tier, innovative, and sustainable access equipment that enhances productivity and guarantees safety on job sites around the world. With decades of expertise, a commitment to continuous improvement, and a focus on customer success, JLG stands as a trusted partner in the industry. Order now and experience unmatched quality and reliability with JLG!
