AGMA A6 Vertical Machining Centre

A-6
Ultra-High-Speed Vertical Machining Center

AGMA once again presents high speed A-series machining centers to a foresighted customer like you with industryleading scraping technology of hardened box way and the technological capacity of manufacturing process. This series of machines are based on high-rigidity Meehanite cast iron and adopt 8,000~10,000RPM belt driven spindle or 10,000 ~15,000RPM direct driven spindle. Three axes adopt high precision linear guideways and ball screws. Also other optional accessories which fully comply with a variety of cutting demand now and in the future are available

Standard Accessories
1. FANUC 0iMD Controller
2. Heat Exchanger for Electric Cabinet
3. Program Execution/End/Abnormal Three Color Indicate Light
4. Quartz Work Lamp
5. Fluorescent Lamp
6. RS-232C Interface
7. Oil Circulating Coolant System for Spindle
8. Spindle Air Blast
9. Automatic Lubrication Equipment
10. Protection device for three axes slide ways
11. Full Splash Guard
12. Rigid Tapping
13. Auto Power Off
14. Y-Axis Screw Type Chip Augers ( 2 pcs) (A-10 only)
15. Tool Box w/ Leveling Bolt
16. Machine and Electric Operation Manual
17. (380/220V) Transformer (Exclude India, USA and Canada)
18. CE/CSA Electrical Specification (For European/Canada Only)
19. Taiwan made Ball-rail linear guide way

Optional Accessories
1. FANUC 31iMB Controller
2. Mitsubishi 70/720/730M controller
3. Belt Driven Spindle 10,000RPM
4. Direct Driven Spindle 10,000/12,000/ 15,000RPM
5. Armless Type 16 tools ATC. (A-10 only)
6. Hinge Type Chip Conveyor
7. Taiwan made PMI roller-rail linear guideway
8. Japan made THK/NSK ball-rail/roller-rail linear guideways
9. Coolant-thru tool holder
10. Three Axes Optical Linear Scale
11. Oil Mist
12. Oil Mist Collector
13. Coolant Through Spindle A Type (20 Bars)
14. Renishaw TS-27R Tool Setup Probe (Tool Setter)
15. Disc Type Oil Skimmer
16. CNC Rotary Table
17. Air Conditioning Equipment for Electric Cabinet
18. 4Th Axis Interface
