AGMA EA600 M2 DRILLING Vertical Machining Centre

AGMA EA600 M2 DRILLING

AGMA once again presents high speed A-series machining centers to a foresighted customer like you with industry-leading
scraping technology of hardened box way and the technological capacity of manufacturing process.

This series of machines are based on high-rigidity Meehanite cast iron and adopt 10,000/12,000/15,000RPM direct driven
spindle. Three axes adopt high precision linear guideways and ball screws. Other optional accessories which fully comply
with a variety of cutting demand are also available.

Standard Accessories
1. FANUC OiMD 8.4" Controller
2. Heat Exchanger for Electric Cabinet
3. Program Executiion/End/Abnormal Three Color Indite Light
4. Quartz Work Lamp
5. Fluorescent Lamp
6. RS-232 Interface
7. Oil Circulating Coolant System for Spindle
8. Spindle Air Blast
9. Automatic Lubrication Equipment
10. Protection Device for Three Axes Slide Ways
11. Full Splash Gu
12. Rigid Tapping
13. Aut Power Off
14. Single Screw Type Equipement on Y Axis Central
15. Tool Box w/Leveling Bolt
16. Machine and Electric Operation Manual
17. (380/220V) Transformer (Exclude India, USA and Canada)
18. CE/CSA Electrical Specification (For European/Canada Only)

Optional Accessories
1. Mitsubish M70V/M720
2. Direct Driven Spindle 12,000/15,000RPM
3. Hing Type Chip Conv
4. Coolant Thru Tool Holder
5. Three Axes Opticl Linear Scale
6. Oil Skimmer
7. Oil Mist Collector
8. Coolant Through Spindle A Type (Cloese Hole-20Bar)
9. Renishaw TS-27R Tool Set up Probe (Tool Setter)
10. Disc. Type Oil Skimmer
11. CNC Rotary Table
12. Air Conditioning Equipment for Electric Cabinet
13. 4th Axis Interface
