AGMA HPA-10 Vertical Machining Centre

Synchronously adopt the European & Japanese design

Wide-span rigid column
Adopt Japan-made NSK extra-large 45mm precise roller-type linear guide way
X/Y/Z axis adopt high specification direct driven motor and high rigid coupling
High quality fully enclosed splash guard. Elegant appearance, well-executed and in good taste.

Extra-large X/Y axis motor
- 4.0/7.0KW

Extra-large Z axis motor
- 7.0KW (no counter balance design)

High reliable and high accuracy ballscrew design
- ø40mm high class double nut provides strong rigidity, high torque, better accuracy, long-life, and effectively heat
- extension control.
- Extra Wide door design
- The width of door reaches 1160mm for conveniently loading and unloading the fixture and workpiece.

Stable air supply equipment
- The gas storage barrel assists to acquire steady air source to increase equipment utility rate.

Standard Accessories
1. Fanuc 0iMD controller
2. Heat Exchanger for Electric Cabinet
3. Program Execution/End/Abnormal Three Color Indicate Light
4. Quartz Work Lamp
5. Fluorescent Lamp
6. RS-232C Interface
7. Oil Circulating Coolant System for Spindle
8. Spindle Air Blast
9. Three Axes Ballscrew Coolant Equipment
10. Automatic Lubrication Equipment
11. Full Splash Guard
12. Rigid Tapping
13. Auto Power Off
14. Chip Conveyor with Chip Cart (For HPA-6 only)
15. Dual Screw Type Chip Augers and Chip Conveyor with Chip Cart. (For HPA-10 only)
16. Tool Box w/Leveling Bolt
17. Machine and Electric Operation Manual
18. (380/220V) Transformer (Exclude India, USA and Canada)
19. CE/CSA Electrical Specification (For European/Canada Only)
20. Precision Roller Rail Linear Guideways

Optional Accessories
1. Fanuc 31iMB Controller
2. Mitsubishi 70/720/730M controller
3. Direct Driven Spindle 15,000rpm
4. Coolant Through Tool
5. Three Axes Absolute Type Optical Linear Scale
6. Oil Mist
7. Oil Mist Collector
8. Coolant Through Spindle A Type (20/70 Bars)
9. Renishaw TS-27R Tool Setup Probe (Tool Setter)
10. Disc Type Oil Skimmer
11. CNC Rotary Table
12. Air Conditioning Equipment for Electric Cabinet
13. 4th Interface
