AGMA VMC-95 Vertical Machining Centre

All three axes have a hardened box-way design. In addition, the spindle headstock, column, saddle, base, and table are all made of high-quality Meehanite cast iron.
All slide-ways are heat-treated and precision ground to maintain high precision.
Double guide-ways and a counter-balanced design prevent unexpected vibration from the Z-axis drive, which helps achieve a quality surface finish.
Strategically placed ribs help enhance the spindle headstock structure. The spindle headstock also has the proper proportion of contact with the column, which creates strong spindle support.

STANDARD ACCESSORIES:

> Fanuc OiMD controller
> Heat exchanger for electrical cabinet
> Three-colour indicator light
> Quartz work lamp / fluorescent light
> RS-232 Interface
> 24 tools arm type (ATC)
> Oil circulating cooling system for spindle
> Spindle air blast
> Automatic lubrication system
> Full enclosed splash guard
> Rigid tapping
> Automatic power off
> Tool box with leveling bolts and pads
> Screw type chip auger 1 pc in front
> Operation manual and maintenance manual
> Forceful cleaning spray-gun
> Transformer (exclude India, USA and Canada)

Optional Accessories

Fanuc 31iMB
Centroid M400
Spindle Motor 11/15KW (15/20HP)
16 Tools Armless Type (ATC)
10,000 RPM Belt Driven Spindle
10,000/12,000/15,000 RPM Direct Driven Spindle
Chip Conveyor
Coolant Thru Tool
Heidenhein Optical Linear Scale
Coolant Through Spindle A Type 20 Bars or 70 Bars
Automatic Tool Length Measurement System
Rotary Table (4th Axis)
Refrigeration Unit for Electrical Cabinet
Data Server
AI contour Control
High Speed Processing (31iMB only)
