AIRMAN 1400CFM 7 – 14BAR VARIABLE PRESSURE PORTABLE DIESEL COMPRESSOR MINE SPEC PDSG1400LVR-5C5 - Hire

Airman is one of the world’s largest manufacturers of diesel compressors. Airman’s PDSG1400LVR-5C5 is a heavy variable pressure (7 to 14 Bar) portable compressor mounted on a bunded skid base. The adjustable pressure feature of the PDSG1400LVR-5C5 assists in handling multiple requirements across a project. A great feature of this machine is that the flow increases when the pressure setting is lowered. At 14bar or 203psi the unit is rated at 39.7m3/min or 1400cfm, however the Airman’s flow rating increases to 42.5m3/min or 1500cfm when the pressure is adjusted down to 7bar or 102psi. This model is new to our rental fleet so contact us today.

Features:
-Skid Mounted
-Quality Japanese manufactured
-Komatsu engine
-Large tanks 780 litres
-Variable Pressure (7Bar, 10Bar or 14Bar working pressure)

Specifications:
-Capacity (CFM)= 1,500
-Working Pressure (psi)= 203/102
-Max. Pressure (psi)= 203
-Aftercooled= No
-Engine= KOMATSU SAA6D 140E-5-B
-Engine Rated Power (kW)= 398
-Fuel Tank Capacity (L)= 780
-Run Time (h 70% load)= 8.9
-Dimensions LxWxh (mm)= 4,750 x 1,950 x 2,050
-Weight (Wet/Dry) (kgs)= 6,610/7,530
-Noise Level dB(A)7m= 74
