4-in-1 Bucket, Hydraulic Quick Hitch
Pallet Fork, Spare Wheel, Toolbox
Up to 3- years / 3000 Hours Warranty with Australian-backed parts
Leading Global Manufacturer
Air Compressor Tank Featuring a Blower
Advanced LED Headlights
High-Definition Rearview Camera
Triple-Layer Articulating Hinge
Climate-Controlled Air Conditioning
Optimal High Departure Angles
Dynamic 4-Speed Transmissions
Enhanced Cabin Comfort with NVH System
Robust Four-Wheel-Drive (4WD) System
Ergonomically Designed Suspension Seat
Advanced Traction Control System
Specification
Engine Model YN4EL120 Turbo Diesel
Engine Pattern In-line, 4 cylinder
Engine Power 119 HP
Engine Speed 2400 r/min
Operating Weight 6600 kg
Bucket Capacity 1.3m³
Rated Load 2,500 kg
Hydraulic System
Operating Type Hydraulic
System Pressure 16 Mpa
Lifting Time 5.8 S
Descent Time 3.8 S
Max Digger Force 55 KN
Max Traction Force 58 KN
Transmission
Axle AWD,LG28 Hub reduction
Gear Shift Double H / L
Pattern Automatic
Transmission Type Hydraulic torque converter
Undercarriage
Max Travel Speed 27 KM/H
Tyre Type 16/70-24
Front Wheel Air Pressure 0.32 Mpa
Rear Wheel Air Pressure 0.28 Mpa
Brake Type Air Break
Dimensions
Overall Dimension 7,110x2,100x2,900 mm
Wheel Base 2,660 mm
Bucket Width 2,100 mm
Max Dumping Height 3,900 mm
Max Dumping Distance 920 mm
Turning Radius 6,550 mm
Steering Angle 33 Degree
Ground Clearance 305 mm
Capacity
Fuel Tank 80L
Hydraulic Tank 70L
