Air Cooled Water Chiller CW-6500 15kW

S&A CW-6500 air cooled water chiller with cooling capacity 15000W and support Modbus-485 communication protocol.

Industrial water chiller machine CW-6500 can provide assured cooling and reliability in a wide range of industrial, medical, analytical and laboratory applications. It features low operating costs, maintenance-friendly design and simple operation. Cooling capacity can be up to 15kW with the stability of ±1?. A powerful compressor is installed to guarantee stable working condition and maximize refrigeration performance for continuous operation. Thanks to its closed-loop design, this industrial recirculating chiller is less likely to be affected by environmental contamination problem and at the same time decreases consumed energy and improves efficiency. It even supports Modbus-485 communication protocol so that communication with the device to be cooled can be achieved.

Description
S&A CW-6500 air cooled water chillers with cooling capacity 15kW
Item NO.:CW-6500VN460TY
Evaporator: 45L;
Refrigerant: R-410a;
Max. pump Pressure: 6.15 bar;
Max. flow: 117L/min;
Pump power: 1.1kW;
Cooling capacity: 15kWkW;
Temperature stability: ±1°C;
Compressor power: 4.6kW;
N.W.: 164Kg;
G.W.: 186Kg;
Package: 112x82x150cm.
