Airtight Solution Timber Shredder EZ8/1

Type: EZ8/1
Throughput (approx. for 16/20 screen) 1.2-2.0 m3/hr of loose wood blocks
Hopper opening: 1000 x 1200 mm
Hopper volume: 1.3 m3
Rotor Diameter: 386mm
Rotor Length: 1000 mm
Rotor Speed: 60 – 100 rpm
Connection: 250 mm
Dimensions (m): 2.4L x 1.4W x 1.7H
Weight: 2800 kg
Power Motor: 18.5 kW motor
Cutting System: 30 x 30 mm Concave headed cutters
Screen Size(mm): 16/20 mm common for chipboard/mdf.
20/25mm common for pine off cuts.
10/12 mm common for briquetting .
Various sizes available depend on throughput required.
Throughput: The throughput rate depends on material composition & screen size
Control: Electronic control using a PLC. All controls housed in an IP44 control cabinet
Voltage: 400 V +/- 5% / 50 Hz
