Akyapak ASM-S 170-15-7 Asymmetric Plate Rolls (8mm capacity, 7mm prebend)

This set of plate rolls from Akyapak is IN STOCK here in Dandenong and ready for immediate sale and delivery.

These are robust, reliable machines built for the most demanding of applications. Akyapak's manufacturing processes are both CE and ISO9001 compliant so you know you're getting a world class machine.

Call our team via the machines4u links to the right to arrange for a demonstration at your convenience.

NEW Akyapak ASM-S Plate Rolling Machine.

Machine Specifications:
- 1600mm working length
- 7mm prebending capacity
- 8mm maximum thickness
- 170mm top roll diameter
- 255mm minimum bending diameter
- 4kW motor power
- 4.5m/min bending speed
- 3300 x 1130 x 1100 machine size (L x W x H)
- 2310kg machine weight

ASM-S series asymmetric plate bending machines are robust and power, with a fully welded steel frame. The top and lower rolls are driven by an eletric motor, gearbox and gear system.

Standard features:
- Induction hardened rolls
- Motorised back roll
- Cone bending device
- Asymmetic working principle
- Top roll can be swiveled out
- Separate, movable control panel
- CE & ISO9001 production quality
