Antonio Carraro Tractor 75hp - TR7600 Infinity Hydrostatic

The TR 7600 Infinity (75hp) is a bifrontal, multipurpose tractor and a completely new model in the Antonio Carraro range. It combines the innovative Infinity hydrostatic transmission with a wide-track ACTIO™ chassis, making it ideal for hay, mountain, or row cultivation on slopes. Powered by a new 74hp, 4-cylinder, turbo-fueled Kohler engine, this model meets Phase 3B emissions standards.

With its reversible drive, the TR 7600 Infinity allows operators to work at the same speeds in both directions. It features two mechanical speed ranges (0-15 and 0-40 km/h), each with three hydrostatic speeds controlled by a joystick selector. These speeds can be engaged while the vehicle is in motion without loss of traction or power, thanks to the variable hydrostatic transmission, also known as "Infinity." The advanced pedal assists with braking, even on slopes, and stops the vehicle when the throttle is released, eliminating the need for brakes or clutch. A reverse gear control is available on the steering wheel lever.

The TR 7600 Infinity offers versatility, functioning as "many machines in one." Its endless applications make it ideal for farmers seeking a fully automatic machine or contractors who frequently need to change direction and gears. The PTO is standard at 540/540E/1000 with independent synchro, ensuring ease of use. This model is the hydrostatic counterpart to the Antonio Carraro TRX 9900, allowing operators to focus solely on steering and attachment operation.

Technical Data
Transmission: Hydrostatic transmission with continuous speed variation and 3 electric, shift-on-the-go ground speeds for each mechanical speed; electrohydraulic reverser; mechanical selector with 2 speed ranges (work and transport); stepless speed variation in both forward and reverse from 0 to 40 km/h; "Automotive" device; electronic speed and RPM control (Cruise Control-Tempomat, combined diagnosis); PTO 540/540E independent and ground speed with progressive electrohydraulic engagement; start inhibit switch on shuttle reverser, PTO selector, and clutch; electrohydraulic front/rear or rear-only differential lock; electrohydraulic disengagement for front drive wheels; hydraulic clutch.

Hydraulic System: Two independent pumps; 2 double-acting distributors (1 floating) with oil reflow and 5 rear quick couplings; lifting capacity of 2400 kg; adjustable lift arms with quick couplings (group 2); height-adjustable rear towing device (EEC type).

Brakes: Hydraulic front and rear oil bath disc brakes; independent rear steering brakes; emergency and parking brake (band-type transmission).

Frame and Driving Comfort: Digital multifunctional dashboard with color display, LED indicators, and diagnostic system; 6-post safety frame mounted on "Silent-block"; hydraulic steering with through-rod cylinder; reversible driving position; adjustable padded seat with safety belts; adjustable steering wheel; rear-view mirror; battery isolation switch.

Warranty: A 2-year warranty is included, with the option to extend up to 4 years.
