Avant 530 Articulated Mini Loader with Telescopic Boom

Lift capacity 950 kg | Lift height 2.8 m | Engine power 26 hp | Drive speed 19 km/h
Unbeatable power/price ratio. Excellent choice with robust and simple hydraulics

The Avant 530 mini loader is in the middle of Avant loader range in terms of size and performance. Avant 500 series compact loaders are well suited for a wide range of industries thanks to their power and straight forward hydraulics, which are needed in many jobs.

The compact dimensions and easy maneuverability allow working in a wide variety of environments. The Avant 530 mini loader can also lift amazingly heavy loads compared to the size of the machine.

Avant 530 articulated compact loader is a reliable partner for all-round use. Like all Avant loaders, it can be customised with a variety of options, including all cab options (L, LX, DLX). The comprehensive Avant attachment range guarantees efficient working all year round.

- Lift capacity 950 kg
- Lift height 2.8 m
- Engine power 26 hp
- Drive speed 19 km/h
- Hydrostatic 4WD
- Optidrive™ drive circuit gives more power for the drive and hydraulic attachments.
- Simple, effective hydraulics means good power and low operating costs
- Easy to transport with a car trailer
- Over 200 attachments for a variety of jobs
- Options available for customisation including cabs

SPECIFICATIONS
Length 2490 mm – 2550 mm
Width see table
Height (with standard wheels) 1985 mm
Weight 1250 + 170 kg
Standard wheels 23×10.50-12” TR
Transmission, drive hydrostatic
Pulling force 1050 kp
Drive speed 9/19 km/h (2 speed)
Aux. hydraulics oil flow / pressure 36 l/min 200 bar
Turning radius inside/outside 995 / 2050 mm
Lifting height 2790 mm
Tipping load * 950 kg
Max. breakout force / 50 cm 1250 kg
Engine make and type Kubota D1105
Engine output (ISO Gross) 19 kW (26 hp)
Fuel Diesel
