Avant Dozer Blade 2000 / 2500 for Avant Mini Loader

Avant Dozer Blade 2000 / 2500 Attachment for Avant Articulated Mini Loader

Equipped with hydraulic blade turning, the Avant Dozer Blade 2000/2500 attachment is the ideal tool for snow removal, earthmoving and similar jobs where the materials must be dozed away quickly.

The curved blade moves material efficiently to the side. Hydraulic slewing, spring release and skid shoes are standard equipment. Also standard are the turnable 2×310 mm extensions, which can be mounted in a straight or collecting position.

The floating system allows the blade to float vertically, which makes working on uneven surfaces considerably easier and more efficient. The blade can also float sideways ± 10°.

The floating system can be adjusted manually in three different positions:
1) Free floating – both vertically and sideways
2) Sideways floating ± 10° only, without vertical floating
3) Rigid position – both vertical and sideways floating locked with bolts

- Two solid skid shoes which reduce blade wear and improve maneuverability
- Robust construction, with spring release mechanism designed for professional use
- Turnable extensions as standard, can be mounted in collection position or straight
- Support wheels, instead of skid shoes, available as an option - keep working height more constant when working on sensitive surfaces
- Advanced blade floating system makes work easier on uneven surfaces
- Avant mini loaders and attachments are manufactured in Finland


TECHNICAL SPECIFICATIONS
Model 2000
Blade width 1390 mm main + 2×310 mm bolt-on extensions
Slewing angle +/- 30 degrees
Weight 215 kg
Blade height 590 mm
Product no A36123

TECHNICAL SPECIFICATIONS
Model 2500
Blade width 1840 mm main + 2×310 mm bolt-on extensions
Slewing angle +/- 30 degrees
Weight 232 kg
Blade height 590 mm
Product no A36251
