FEATURES
2-way swivel head enables from 0° to 60° mitre cuts.
Semi-automatic machine.
Dual direction heavy-duty vice.
Hydraulic blade tension gauge.
Incorporated recirculating coolant system.
Brass chip brush to help prevent blade breakage.
Adjustable material stop for repetitive production.
Remote emergency stop non-voltage return safety switch.
12 months warranty.
Comes complete with stand blade.
Made in Taiwan.
SPECIFICATIONS
Motor: 2.0hp Three Phase (415V)
Blade Speed: 2 Speed 36 / 72mpm
Blade Size: 27mm x 0.9mm x 3160mm
Bed Height: 890mm
Weight: 530kg
90° Cutting Capacity:
Round: 260mm
Square: 260mm
Rectangle: 350 x 250mm
45° Right Cutting Capacity:
Round: 230mm
Square: 165mm
Rectangle: 240 x 110mm
60° Right Cutting Capacity:
Round: 150mm
Square: 90mm
Rectangle: 150 x 90mm
45° Left Cutting Capacity:
Round: 200mm
Square: 170mm
Rectangle: 260 x 60mm
