Engine
Duetz, BF-4M, 2011 64 HP Turbo Diesel
Welding Mode
CC/DC
CV/DC
Rated Output
600A, 44V 40% duty
500A, 40V 100% duty
400A, 36V 100% duty
Welding Current Range
20 - 750 Amps
14 - 40 Volts
Auxiliary Power
4000 W 1 ph
240V While Welding
Air Compressor
100 PSI 60 CFM 100% duty
Dimensions
Height 1092mm
Width 724mm
Depth 1715mm
Shipping Weight
899kg
Applications
Onsite maintenance and fabrication (mining, railroad, service & repair rigs).
Features
ONE MACHINE THAT WILL DO IT ALL!
The Big Blue Air Pak is the complete mobile welding, air and power workshop for onsite maintenance and fabrication.
WELDING
Full Multi-Process.
750 amp welding machine suitable for Stick, MIG, Flux cored, Submerged Arc, AC/DC TIG & Plasma Cutting.
AIR
Ingersoll-Rand.
Ultra-reliable industrial rotary screw air compressor (100 PSI 60CFM) with a life expectancy of 30,000 hours. Runs pneumatic tools with ease (such as rattle and needle guns, small rock drills and arc air gouging).
Ingersoll-Rand ultra-reliable industrial rotary screw air compressor. Belt-driven with automatic belt tensioner with a life expectancy of 30,000 hours.
POWER
Auxiliary Power.
For lighting and power tools.
Deutz Turbocharged 64HP Diesel Engine.
Provides more horsepower for better performance.
Low Maintenance.
With easy single-side access to engine and 500 hour oil changes for both engine and compressor.
Quiet Performer.
For improved worksite communications and safety. Only 70db while at idle.
The Vault.
The ultimate in circuit board protection and reliability.
