Bobbin Sander Tilt table

HOT DEAL . BIG SAVING ON CURRENT STOCK.

OVS-JM - Vertical Oscillating Bobbin Sander with Cabinet Stand
Ø1/4 - 4" Sanding Sleeves
Tilting Table To 45 Degrees

Used for sanding deep and wide work pieces, front edges, narrow inner curves, horizontal, vertical, diagonal, with or across the grain
The rubber drum can be fitted on both ends to fully utilise the entire spindle
Bobbin oscillation stroke of 38mm to spread workload on sandpaper sleeves
This machine accommodates ten sizes of spindle from 1/4" to 4", diameter to fit the various rubber drum diameters
The tilting table can be easily tilted by loosening the two lock knobs located at both sides under the table for the sanding of bevelled parts. A graduated scale is attached to read the tilting degree dust hood outlet is 4" diameter
Spindle change is easily made
The oscillating sanding provides an extremely fine sanding finish
Easily interchanged spindles
The tilting table is precision ground
Heavy gauge steel frame
convenient storage of all drums and table inserts plates
Heavy duty precision ground cast iron tilting table 609 x 609mm
Rotating and oscillating action
Powered by an 1hp 240V motor
Oscillating per minute: 75 times
Sanding spindle speed: 1725rpm
Table height: 990mm

Includes
Sanding Spindles & Sleeves:
1/4" x 5" long
3/8" x 6" long
1/2" x 6" long
5/8" x 6" long
3/4" x 9" long
1" x 9" long
1-1/2" x 9" long
2" x 9" long
3" x 9" long
4" x 9" long
