CLEANQUIP-VIPER AS530R RIDE ON SCRUBBER DRYER

The AS530R is the first mini ride-on scrubber dryer in the user-friendly Viper series, known for providing high cleaning efficiency at attractive prices. With battery and tank capacity to clean for hours, this machine is ready to take on areas of more than 5.000 m2.

An ideal choice for cleaning in hotels, bus and train stations, supermarkets, exhibition centers, shopping malls, schools and other institutions.

Using the machine provides the same level of comfort as the larger ride-on scrubber dryer: The intuitive display with all major functions and the battery status makes it easy to control, together with the large buttons, and the clear view of the water/detergent level indicator. Also adding to the user comfort is the USB-port for fast charging of cell phones and tablets.

The big steering wheel ensures that the AS530R is easy to maneuver with a minimum of training, and when driving, comfort is added by the automatic braking system engaged when the pedal is released. Another benefit is that the squeegee can be placed on the hanger behind the main body when the machine is driving through narrow passages.

All handling can easily be carried out when it is time to empty, refill or clean the tanks of the scrubber dryer. Service and maintenance are also convenient, i.e. with direct access to dismounting or mounting of the driving motor if needed. All in all, the AS530R is easy to use and offers fast, effective cleaning at a very competitive price.

An integrated on-board charger enables easy plug-in and battery charge at any outlet
Water solution level indicator with volume visible on the tank
Large opening to the 73 liter recovery tank allows easy cleaning
Built-in squeegee hanging system on recovery tank for easy machine transfer in narrow areas
Productivity: Working width 53 cm, Squeegee width 73 cm
Versatility: Cleans tiled floors, vinyl, sealed wood, marble, concrete and other surfaces
Efficiency: Speed 5.5 km/h, Climb rate 10%
High performance: Brush pressure 23 kg, Brush speed 160 rpm
Low sound level: 69 dB(A) enabling daytime cleaning
Robust design: Front bumper, strong main frame and heavy-duty aluminum squeegee
User-friendly dashboard: Intuitive display and buttons

Technical Data AS530R
Input Volts 24
Vacuum Motor Watts 400
Brush Motor Watts 450
Max. Speed km/h 5.5
Scrubbing Width mm 530
Brush/Pad Diameter mm 530
Brush/Pad Pressure kg 23
Squeegee Width mm 730
Productivity Rate m2/hr 2650
Solution/Recovery Tank L 72/73
Sound Pressure dB(A) 69 +/- 3
Machine Dimensions L x W x H mm 1360x580x1120
Net Weight kg(empty tanks, not batteries) 200

AS530R Ride on Scrubber Dryer
Includes:
VR25014 Brush Kit
VR25022 Pad holder
VR26000 Squeegee assembly
VR21053 On Board charger
EV31A-A Battery (x4)
VR17160 Warning Beacon kit
VR25025 Skirt Right Kit
VR25026 Skirt Left Kit
