Compact Tractor 25HP Trencher - Built to last and made in New Zealand!

TrenchIt Tractor Mounted Trenchers are low maintenance, built to last and made in New Zealand.

Backfilling is made easy with the fully hydraulic 6-way blade.
Twin soil augers place dirt neatly alongside trench for ease of backfilling.

A wide range of trenching sizes from 100 to 200mm wide and up to 1.1m deep with digging boom and chain.
Permanently offset trenching for good operator view.
A compact model ideal for the smaller spaces/work sites & easy to transport around on your trailer.

FEATURES
PRIME MOVER Kubota B2601 Diesel Tractor
HYDRAULIC SYSTEM is a joystick control for blade. Single control for boom raise and lower.
BACKFILL BLADE is fully hydraulic, raises and lowers, tilts left and right, angles at 30° maximum
DIGGING CHAIN is heavy duty 1.654 Pitch, being fully detachable and hard wearing.

DIGGING TEETH are tungsten carbide made for hard abrasive soils.
TRENCHING OPTIONS: –
Side Mounted 100 – 200mm Wide
Standard Width 100/ 150 mm
Standard Depth 1.1 metre
CRUMBER BAR grades trench as you go.
SPOIL HANDLING Twin augers place soil along trench.

The TrenchIt Tractor Mounted MT B2601 Trencher with 6-way blade setup is a rugged, strong and powerful trencher.

The Kubota B2601 tractor is the ideal tractor unit to team up with our MT trencher & blade, for working on light construction, or landscaping, farm work or for the contractor doing electrical cables or the plumber laying irrigation.
