Cosen M8 CNC Double Mitre Automatic Bandsaw. Mitsubishi CNC, intelligent design.

Call us via the phone number to the right, or leave a web enquiry and we'll get back to you ASAP.

This double mitre, automatic CNC bandsaw from Cosen and Applied Machinery is a feature-packed machine built on a rock solid, precision foundation for accurate, reliable, repeatable cutting.

----------------------------

NEW Cosen M8 CNC Double Mitre Automatic Bandsaw.

Features and specifications include:

- Capacity at 0° (mm): 500 round, 500H x 500W square, 400H x 800W rectangle
- Capacity at +/-45° (mm): 500 round, 500H x 500W square, 400H x 550W rectangle
- Capacity at +/-60° (mm): 400 round, 400H x 400W square, 400H x 400W rectangle
- 20-100m/min blade speed
- 7310 x 51 x 1.6mm blade size
- hydraulic blade tension with pressure gauge
- carbide guide
- cleaning via powered wire brush
- 10HP saw blade motor, 3HP hydraulic motor, 0.5HP coolant pump motor
- 2000mm feeding stroke
- 850mm work bed height
- hydraulic powered chip conveyor
- variable vice pressure regulator
- full stroke cylinder vice
- floor space (mm): 4000 x 3475 x 2620

Mitsubishi Computerised Numerical Control features include:

- Touch panel entry of programmable quantity, angle and length of cut with automatic shut-off for finished job(s) or out of stock.
- Stored program(s) may be easily recalled and executed at will.
- LCD Screen with Touch Panel Type Key Pad
- Blade Speed Display
- Blade Life Indicator
- Feed Vice Position Display
- Automatic Kerf Loss Compensation & Automatic Multiple Indexing up to 99M
- Error Code Display Provides simplified self-diagnostics.

Optional Extras:

- 2m roller table
- automatic wedging resistance
- blade deviation detector
- vibration damper
- mist spray coolant system
