DMC Turning Centre (Korean) - DL30 (READY FOR SHIPPING)

Machine ready to ship, have on your shop floor in May.

DL S series is designed to offer the best features of heavy-duty cutting, a sufficiently large workspace, a heat distortion prevention system, and highly efficient machining to satisfy customer needs.

Options on this machine:
Air Blow
A/C
Air gun
Chip bucket
Chip conveyor
Coolant gun
Coolant pump up to 1.8kw
Hard jaw
Soft jaw
Oil skimmer
Tool setter (Marposs, removable)
Transformer
CF memory card

Swing over Bed: 610mm
Swing over Cross slide: 480mm
Max. Turning Dia: 400mm
Max.Turning Length: 1,080mm

Max.Spindle Speed: 3,000rpm
Spindle Nose: A2-8
Spindle Bore: 105mm
Max. Spindle Torque: 47.9kgf
Chuck Size: 12inch

Main Spindle Motor: 15/18.5kW
X-axis Servo Motor: 3kW
Z-axis Servo Motor: 3kW

X-axis travel: 230mm
Z-axis travel: 1,130mm
Guideway Type(X/Z): BOX Way
X-axis rapid traverse rate: 20m/min
Z-axis rapid traverse rate: 24m/min

Turret Index Type: Servo
Max. No. of Tools: 12
Turning tool shank size: 25mm
Borning bar diameter: 50mm
Turret Indexing Time: 0.2


Who is FFG DMC

FFG DMC stands as a renowned name in the CNC machining industry, renowned for its precision engineering and innovative solutions. Since its inception, FFG DMC has been dedicated to delivering top-quality machinery to meet the evolving needs of manufacturers worldwide.

360 Automation and FFG DMC Partnership.

In a significant collaboration, FFG DMC has joined forces with 360 Automation to extend the reach of its advanced CNC machines. As an appointed representative of FFG DMC, 360 Automation ensures businesses receive comprehensive support, from initial consultation to installation and beyond. This partnership underscores a shared commitment to delivering cutting-edge technology and unparalleled service to clients across various industries.
