Primary Voltage
415 VAC
Input Power
380/400/440 Volts 50/60Hz
Rated Output
450A 38V, 100% duty (602)
650A 44V, 100% duty (812)
Welding Current Range
50-600 Amps (602)
50-850 Amps (812)
Dimensions
H 762mm | W 585 mm | D 966mm
Shipping Weight
174kg (602)
214kg (812)
Applications
Deltaweld machines are engineered with power and endurance for tough manufacturing work.
Features
Name your welding wire job and the Deltaweld will tackle it: heavy machinery, trucks and trailers, railcars, pressure vessels, structural steel, sheet metal fabrication, automotive components, metal furniture and more.
Deltaweld models are available in 300, 450 and 650 amps. Choose the model that best suits your welding
Line voltage compensation keeps welding parameters constant even when input voltages change ±10%. Eliminates need to change welding parameters throughout the day.
Two positive output terminals allow operators to optimize arc performance.
Unique Fan-On-Demand™ cooling system operates only when needed. Reduces contaminants drawn into the machine and excess noise in work areas.
Enclosed circuit board provides additional protection by eliminating contaminants which cause premature failure of components.
Thermal overload protection internal components are protected from damage by thermal overload protection which automatically shuts down the unit if duty cycle is exceeded or air flow and cooling are restricted.
Remote control capability allows operators fine tuning capability at an extended distance.
15 amp 115 VAC duplex receptacle allows operators the flexibility to run grinders, drills, coolers, etc. from power source without the need for additional 115 VAC power in weld area.
Power efficient for exceptional value and return on your investment.
Digital meters for presetting or monitoring welding voltage or amperage for more precise control.
