Dingo Wheeled Mini Loader

Designed and manufactured exclusively for Wacker Neuson by Dingo Australia, powered by the Yanmar diesel engine, the SM440-31W is the ideal platform for worksites, owner-operators and DIY‘ers. The lean fuel burn of the Yanmar, delivers excellent fuel economy reducing running costs.

Pressure and flow to the track and your attachments are the heart of any mini loader – it’s how you earn your living. You want the very best – and that’s what a SM440-31W provides consistently – day after day, year after year!

Combining the unique hydraulic design of the Wacker Neuson mini-loader with the Yanmar engine, provides the perfect partnership of power, pressure and durability for every application.

The SM440-31W has the most robust chassis on the market – this moves the weight down to the track where you need it.

The lower center of gravity gives you best in class traction and trenching up to 30% more pull and 30% more push power.

The Wacker Neuson Dingo all-wheel drive SM440-31W is perfect for all terrains.

With the optional narrow wheel and hub set you can quickly change your set up to narrow access whenever you need – as narrow as 780 mm – eliminating the need for a second machine.

Achieve more with the best and highest lift for the weight class. Our proven bushing system has no steel on steel wear – which means no grease no mess resulting in less maintenance and longer machine life!

Protected by our touch powder-coated finish, your SM440-31W will stand up against the harshest of conditions.

Wacker Neuson SM440-31W made by Dingo Australia, working as hard as you do!

Please note that product availability can vary from country to country. It is possible that information / products may not be available in your country.

SM440-31W Technical specifications


ENGINE / MOTOR
Engine / Motor manufacturer : Yanmar
Engine performance : 27 hp
Engine / Motor type : 3TNV76

DIMENSIONS
Ground clearance : 170 mm
Width (overall) : 850 – 1,050 mm
Height (overall) : 1,225 mm
Overall length : 1,600 mm

OPERATING DATA
Travel speed (max.) : 9.5 km/h
Angle of departure : 25 °
Operating height 4 in 1 : 2,675 mm
Wheelbase : 800 mm

WEIGHTS
Weight : 1,080 kg
