Primary Voltage
380-575 Vac
Input Power
Refer to leaflet AD/5.0
Open Circuit Voltage
75 Volt DC
Rated Output
300 Amps 60% DC
Welding Current Range
5 - 350 Amps
Dimensions
H 629mm | W 349mm | D 559mm
Shipping Weight
61kg
Applications
Suitable for a wide range of industrial applications, from precision sheet metal to pipe and pressure vessel fabrication.
Features
Fan-on-Demand
Advanced Squarewave arc
For improved weldability on aluminium and magnesium using low power. Continuous high-frequency is NOT needed because of the advanced Squarewave arc, and extended balance control allows you to fine-tune the duration of the electrode negative portion of the cycle from 50 to 90%. This provides precise cleaning control and prolonged tungsten life.
Programmable HF start parameters
Allows the operator to independently set HF starting conditionbs based upon process amd memory selection.
Autoline
Provides connection to 380V to 575V, three phase power without having to remove the covers and relink the power source.
Lift-Arc start
For TIG arc starting without the use of high frequency.
