ES1932 Electric Scissor Lift - 5.80m Platform Height, Efficient, Low Maintenance

JLG - ES1932 Electric Scissor Lifts
ES Series Scissor Lift

Features:
Quieter, cleaner operation for a variety of environments, both indoors and outdoors.
Electric drive with integrated components, featuring only two hydraulic hoses and four hydraulic fittings, reducing the chances of leaks and service calls, thus lowering operating costs.
Narrow width allows it to fit through most standard doorways and tight aisles.
Quick Specs:

Power Source:
Batteries: 4 x 6V 220 amp-hr
Charger: 27 amp
Drive: 24V Electric Front Wheel
Hydraulic Reservoir:

Capacity: 12 L
Pump: Fixed Displacement Gear
Tyres:

Tyre Size/Type (Non-Marking): 232 x 102 mm
Brakes:

Electric / Multi-Disc Friction

Key Features:
Proportional Controls
Load Sensing System
DC Electric Drive
Smart Battery Charger (CAN Enabled)
Battery Condition Indicator
All Motion Alarm
Horn
Hourmeter
Tilt Alarm and Light
Lanyard Attach Points
Moveable, Removable Platform Control
Nickel Plated Pins
Lubrication-Free Scissor Arm Bushings
Scissor Maintenance Prop
Active Pothole Protection System
Lifting and Tie Down Points
Fork Lift Pockets
Foot-Actuated Deck Extension
Steel Swing-Out Doors
Variable Tilt Visual Zone Indicator
Manual Descent Cable
Diamond Tread Steel Deck
Greaseless Kingpin Joints
Analyzer Port for Diagnostics
Dynamic Braking
Flashing Amber Beacon
Self Closing, Self Latching Gate
Fold Down Rails
USB Charger and Phone Holster
MDI (Ground)
Drive Motor Covers
AS/NZS 1418.10 Compliance

Performance Data:
Platform Height: 5.80 m
Platform Capacity: 230 kg
Capacity on Platform Extension: 120 kg
Occupants (Indoor/Outdoor): 2 / 1
Lift/Lower Time: 22/24 Seconds
Maximum Drive Height: Full Height
Weight: 1550 kg (Certain options or country standards may increase weight)
Ground Bearing Pressure: 8.0 kg/cm²
Drive Speed (Elevated): 0.8 km/h
Drive Speed (Lowered): 4.8 km/h
Gradeability: 25%
Turning Radius (Inside): Zero
Turning Radius (Outside): 1.7 m
