ON REQUEST (ACCESSORIES)
- In-built GPS device
Materials
HDPE/PP/PP-R
Working range
Ø 20 ÷ 315 mm - 1/2" IPS ÷ 12" IPS (110 V)
Ø 20 ÷ 200 mm - 1/2" IPS ÷ 6" DIPS (230 V)
Power supply
110 V ±15% single phase 50/60 Hz
230 V ±15% single phase 50/60 Hz
Total abdorbed power (60% Duty Cycle output)
1700 W (110 V)
1800 W (230 V)
Max output current
60 A - 110 V
70 A - 230 V
Working temperature range
-20° +50° C
Memory capacity
8000 reports
Protection degree
IP 54
Dimensions
246 x 390 x 240 mm
Dimensions carryng case
290 x 445 x 295 mm
Weight machine body + welding and
power supply cable + laser scanner
8,4 Kg
