FAE PTO /MTH STONE CRUSHER FOR TRACTORS *ITALIAN ENGINEERING*

FAE multi-function head for tractors from 300 to 500 hp.
The top-of-the-range FAE multi-function machine enabling milling of rock slabs, crushing of stones, milling of asphalt and ground stabilization, with a maximum operating depth of 50 cm.
The gear transmission enables operation with constantly optimal levels of torque and power.
The variable displacement chamber guarantees excellent results in terms of breaking down material.
The volume of the chamber increases based on depth with a reduction in fuel consumption and an increase in operating speed.
The Hardox® wear-resistant counter blade and grid on the rear hood guarantee the desired granulometry of material processed.

TRACTOR
from 300 to 500 hp

WORKING DEPTH
50 cm max

MOST IMPORTANT FEATURES
VARIABLE DISPLACEMENT CHAMBER
THE RESULT IS A HOMOGENEOUSLY STABILISED SOIL AT ALL WORKING DEPTHS

WIDE OPENING
TO EFFICIENTLY PROCESS MORE MATERIAL

INTERCHANGEABLE HARDOX® INTERNAL AND SIDE GUARDS

APPLICATIONS:
STONE CRUSHING
ROCK CRUSHING
STABILIZING STONY SOILL

STANDARD EQUIPMENT
Hydraulic front hood
Bolted grid on rear hood
Interchangeable inner antiwear plates in Hardox®
Enclosed/anti dust machine body
Variable displacement chamber
Inside lateral protection
Bolted on protection chains
Flat pressed welded steel counter-blades
Adjustable Hardox® counter-blade
Transmission with side gearbox
Side gearbox with oil cooling system (HP)
Gearbox with freewheel
PTO shaft
Friction clutches
Gearbox with oil cooling system (HP)
Bolt-on rotor shafts (in forged steel)
Hydraulic top link
Dozing blades with spring system
Adjustable skids

At Agriculture & Forestry Equipment we don’t just sell great products, we work with you to determine the best equipment fit for your requirements. Our recommendations are based on decades of real world experience working with hundreds of operators and the servicing of their equipment.
Interested in this machine? Send us a message and we will get back to you with all the information you need, or give AFEquip a call to discuss your best solution. Please visit our Machines4U showroom to see the full range of our equipment.

*Click on the PDF spec sheet for more detailed information*
