FARMTECH VIKING V3000GDL BELT SPREADER (3000L)

Working with vineyards doesn’t mean you have to settle for smaller, lesser-capacity spreaders. Running out of materials while you’re out in your vineyard when there’s still plenty of ground to cover is a huge waste of time and resources.

Introducing the Iris Viking 3000L with a 3-ton hopper! High-capacity, ground-driven, belt spreader specialized for vineyard utility with its lowered stance!

Equipped with Ground driven Spinner Unit to ensure maximum efficient output even with wider coverage. Comes with Hydraulic Outlet controls and a stainless mesh Conveyor belt for more accurate dosing at bigger loads.

Easy and conveniently dispatch 3 tons of lime, gypsum, compost, and dry fertilizers over your vineyard!

Certified for lime, gypsum, compost, and dry fertilizers
Ground Driven Spinner and Agitator
Hydraulic controls with 180° Full-Width Spreading

“High-Quality Product”

Built using the highest grade stainless steel for maximum protection against rust and corrosion inside and out.

“Stainless Mesh Conveyer Belt”

A significant upgrade over conventional rubber belts. Stronger, more durable, and more capable of a steady and accurate action at sustained speed and load.

“Longer Service Life”

All Iris Viking Spreaders are equipped with a Relief Valve to keep the Hydraulic Motor from overloading resulting in improved serviceability and durability.

FEATURES
Stainless mesh conveyer: It conveys a more exact amount of fertilizer or sand and is more durable than rubber conveyers
Stainless Steel parts: A hopper, feeding conveyer belt, spinner discs, vanes, and prevent the plate
The speed of the spinner disc can be controlled by a valve
Ground driven: As the fertilizer that fed into the spinner disc varies according to the rotating speed of a wheel, it is possible to spread evenly regardless of the speed of a vehicle (As a result, the faster a vehicle run the larger amount of fertilizer is fed, the slower a vehicle run the smaller amount of fertilizer is fed)
Hydraulic automatic system: The operation of conveyor and that of fertilizer outlet is linked both are controlled by one hydraulic lever
Relief valve: Durability of hydraulic motor for spinner disc is improved by installing relief valve (It controls the pressure that occurred when the motor stops and overload)
Hydraulic outlet shutter: The outlet size can be controlled and fixed as you want
Windows to see inside fertilizer
Safety grill: Optional
Twin side conveyors: Optional for orchards & vineyards
Hydraulic-driven system: Optional

Specifications: Viking 3000
Hopper Capacity: 2.7m3
Nominal Capacity: 3,000kg
Spreading Width: 20-25m
No. Discs: 2
Outlet Shutter Control: Hydraulic
Spreading Pattern: 180 Degrees
Weight: 1,185kg
Length: 4,330mm
Height: 1,795mm
Width: 1,800mm
Feed Mesh Chain Width: 500mm
Disc Size: 600mm
Hopper Material: Stainless Steel 430
Axles: Single
Tires: 11.5/80-15.3 x 2
Type: Pull
Power: Ground Driven Belt / Hydraulic Spinner

Machine/Equipment base price only, additional price for optional extras.
