One of the best value-for-money wide belt sanders It comes from a new generation factory established in China, using design and quality control from Europe and is suitable for sanding solid timber (not veneered panels).
Download the Feature: Benefit Report for full details
LEDA MODEL 1300 SINGLE BELT WIDE BELT SANDING MACHINE equipped as follows –
Sanding Unit
80 Shore rubber covered contact roller and platen combination for fine finishing.
22 kw motor. Disc brake for emergency stop.
1300mm maximum working width.
Electric rise and fall of feed conveyor table with key pad programmable automatic height setting of the feed table using an electronic controller and digital readout.
Long 2200mm sanding belt for extended life.
Efficient dust extraction cowlings inside machine.
Heavy, accurate construction of machine.
Rotary bristle workpiece cleaning brush at rear.
Safety flap with limit switch at infeed position, to stop machine and lower the feed conveyor in an emergency.
Pricing is ex the LEDA Warehouse / stock location and excludes delivery from there to your factory, Commissioning costs and GST
TRADE INS WELCOME and COMPETITIVE Finance options available T.A.P.
Contact us for details
Specifications
Maximum working width 1300 mm
Full range of working height 2.0to 160 mm
Feed drive motor 2.2kw
Variable speed feed drive to 22 m/min.
Table rise and fall motor 0.37kw
Dimensions of sanding belt 1330 mm x 2200 mm
Nett weight of this machine approx. 2700 kgs
