FORKPAC - LINDE E20PH-01 COUNTER BALANCE FORKLIFT

Load Capacity: 2.0T
Power unit : Battery
Operation: Seat

The E20PH-01 electric forklift offers outstanding stability and excellent traction thanks to a design that incorporates high-level engineering expertise and high quality materials. In particular the advanced drive axle concept provides a superior driving experience by automatically varying the wheelbase. When the mast is tilted back for driving, the wheelbase extends giving greater stability and safety. When tilted forward, the wheelbase is shortened and is ideal for manoeuvrability in confined spaces

Linde electric trucks deliver powerful electric motors with intelligent control. Together, these factors form an impressive and compact powerpack that delivers the benchmark in optimal productivity:

Powerful twin AC motor traction system with maintenance free AC motors contains no carbon brushes, and has an enclosed axle which offers excellent heat dissipation with thanks to cooling fins on the axle casing.
Precise control is provided by the perfect interplay between the twin-motor front drive and Linde Load Control. This allows all lift mast functions to be operated effortlessly with the slightest finger movement, and operators can lift and tilt at the same time
Pendulum axle provides enhanced stability, increased manoeuvrability and safe operation in narrow aisles.
Dual pedal control enables fast direction changes as well as precise, relaxed and intuitive operation.
Moving front axle provides enhanced stability for distance travel when you engage the backward tilt i.e, the load wheels extend further out, providing you with a longer wheelbase and giving you more stability all round.
The power module is mounted on the traction axle, allowing for minimal power loss to the drive motors, providing effective optimisation of the motor.
Exceptional residual capacity with full load capacity up to maximum lift height.

European manufactured cutting edge drive and lift motors plus contact-free hydraulic mini levers underline the premium standard of this electric truck:

Fully sealed aluminium component housings provide superb protection from dust and dirt ingress resulting in less need for cleaning.
Four different battery change solutions.
Preventative maintenance service only needs to be carried out every1000 operating hours.
Hydraulic oil only needs to be changed every 3000 hours.
Standard 180 degree battery door for quick vertical and lateral battery changes.
Maintenance free AC motors.
Easy fault diagnosis is available through the Linde digital control system.

OPTIONAL EQUIPMENT

Cabin heating

Lever configuration

Lighting

Drive in racking

Cold store protection

Dual pedal configuration
