Felder RL125 Dust Extractor - SINGLE PHASE

FELDER RL-125 Clean Air Dust Extraction Unit

Amazing Clean Air Dust Extraction Systems with built in filtering system


Please download PDF sheet for available machine options


Certified for internal use and returns clean, filtered air to the workshop.

Standard Features:

Manual Filter Cleaner
Mobile - mounted on lockable castors
Acoustic Damper Available - option
Motor: 3 x 400V 4 HP

Max. airflow m³/h 1900
Nominal air flow capacity m³/h 1150
Min. air flow capacity 20 m/sec. m³/h 884
Static pressure Pa 1350
Static pressure (at machine) Pa 1850
Dimensions mm (L x W x H) 940 x 780 x 1600
Extraction connector Ø in mm 125
Dust emission quality mg/m³ < 0,1
Filter surface area m² 5
Acoustic pressure (with sound absorber) dB 80
Chip volume litres 200
Weight, kg (with standard equipment) 210 KG

Price DOES NOT included any piping.

Price excluding GST & Delivery and Setup
