Formula SR 650 Radial saw

The SCM formula sr 650 is a radial saw made of a heavy cast-iron structure, with 650 mm trimming capacity, that guarantees the maximum cutting precision.

Adaptability, versatility, cutting precision and easy maintenance make this product line an essential machine for daily use in any artisan workshop.

-Cutting unit with spring return system to increase safety
-Interchangeable sliding ways to reduce the machine setup times
-Rear extraction hood to always have a clean working environment
-Electronic motor brake

Additional Information
Column protection cover for a long-lasting functionality
The mechanisms of which the machine is equipped, as the protection cover on the arm column support, protect the mechanical parts from dust, guaranteeing the best operation over time

The carriage with 8 bearings ensures precision and smoothness
The 8 sliding bearings on the guides grant the best carriage smoothness and an optimal support for a perfect cutting result

Blade guard which ensures the absolute operator’s safety

Cast iron arm with steel interchangeable guides for maximum cutting precision

The cast iron structure provides the arm the maximum solidity and rigidity. The interchangeable sliding ways allow the operator a simple and rapid replacing, in case of wear, without direct intervention on the arm

TECHNICAL FEATURES
Blade diameter mm 350 ÷ 400
Blade tilting -45° ÷ +45°
Max. cutting depth with blade at 90°/45° mm 120/83*
Cross cut capacity mm 640 x 20
Three-phase motor 3kW (4hp) 50Hz
Machine dimensions mm 1260x1140x890
Gross weight kw 259
Installation requiremens
Compressed air consumption [Nl/ciclo] –
Exhaust air consumption [m3/h] 205
Exhaust air speed (dry shavings) [m/s] 20
Installed motor power [VA] 3000
CE version – voltage/frequency 400EU /50
