Fuho Vertical Bandsaw - VBS1610E

The 16” Fuho vertical bandsaw has higher speed range and more features than most of the conventional vertical saws. It is a standard need for industrial use.
Max Throat Capacity – 396mm
Max Work Height – 255mm

Blade Speed
60HZ – Low 25-100, HI 300-1200 M/min, Low 82-330, HI 985-3950 F/min
50HZ – Low 20-80, HI 250-1000 M/min, Low 65-265, HI 820-3280 F/min
Table Size – 550mm x 600mm

VBS-1610/ VBS-1610E has a higher speed range and more feature than most of conventional vertical saws, it is a standard need for industrial use. Equipped with vartable speed pulleys combined with a HI-LOW gearbox. This model can handle most metals and non metal materials

Model
VBS-1610
VBS-1610x
MAX. THROAT CAPACITY
396 mm ; 16 inch
MAX. WORK HEIGHT
255 mm ; 10 inch
WHEEL DIAMETER
408 mm ; 10 inch
BLADE SPEED 60 Hz
Low 25-100 ; HI 300-1200 M/min
Low 82-330 ; HI 985-3950 F/min
BLADE SPEED 50 Hz
Low 20-80 ; HI 250-1000 M/min
Low 65-265 ; HI 820-3280 F/min
MAIN DRIVE MOTOR
2 HP ; 1.5 KW x 3 PH
TABLE SIZE
500 x 600 mm ; 20 x 24 inch
TABLE TILT
R-15°, L-12° ; 8° EACH F&B
5° EACH L&R; FLAT F&B
TABLE HEIGHT
1000 mm ; 39-3/8 inch
MAX. BLADE LENGTH
3150 mm ; 124 inch
MAX. BLADE WIDTH
16 mm ; 5/8 inch
WELDER CAPACITY
16 mm ; 5/8 inch
MEASUREMENT
940 x 675 x 1840 mm
37 x 26-1/2 x 72-1/2 inch
NET WEIGHT
410 kgs
435 kgs
TABLE FEED POWER
80 kgcm, 110V
TABLE STROKE
300 mm; 12 inch
