G.A.D.E. CO 40/4 HYDRAULIC GUILLOTINE SHEAR “BUSINESS” SERIES

MAIN FEATURES:
Monolithic welded structure base machined and bored in a single operation on a boring
machine with movable column.
Top blade carrier made of a robust L-shaped structure which prevents from any deflection in
the central part, sliding on considerable sized anti-friction guides placed at the two extreme
sides of the machine.
Independent hydraulic hold-downs with simple effect spring return controlled by the main
hydraulic circuit. Possibility to control the hold-downs independently from the blade descent
( useful when working on marked sheets ).
The hydraulic group is entirely managed by a gear box including all valves which allows to
perform the various functions available on the machine.
The best values achieved by the system we use is the extreme smoothness of operation and the
possibility to cut the max thickness allowed in every point of the blade length without risk of
machine displacement or creating other damages.
All models of our shears are equipped with variable rake angle controlled by CNC.
This allows to cut always in optimum conditions any kind and thickness of material.
The variable blade gap system (standard in all models of the BUSINESS and TOP series )
allows always the best quality cut without risk of overloading the machine and granting a long
lifetime of the blades.
Main hydraulic cylinders are double acting with lapped barrel, chrome plated piston rod and
forged steel heads.
Main components of the electrical circuit are SCHNEIDER.
Components of the hydraulic circuits are H+L - ATOS

STANDARD ACCESSORIES
– ELITE 110 control with 3 axes to manage back gauge, rake angle and blade gap based on
type and material thickness. The back gauge stroke is of mm 1000, with hardened ball
screws and a.c. motor with inverter.
– Ruled squaring arm with “T” slot L= mm 1000.
– N° 3 Front support arms with “T” slot L= mm 1000.
– Shadow line cutting.
– Pneumatic rear sheet support
– Bench with ball bearings.
– Independent command of hold down units.
– Variable rake angle.
– Two edge blade with a 3° angle suitable for stainless steel material.
– Movable footpedal.
– Emergency pedal.
– Front finger protection- fixed.
– Rear protection through light guards.
– Fixed side guards on gaps (removable only by releasing the relevant screws ).
– First filling hydraulic oil.
– Automatic lubrication pump of the guides.
– Painting with color codes RAL 173 – 7047 and RAL 5001.
– INSTRUCTION USE AND MAINTENANCE MANUALS.
– ELECTRICAL TEST REPORT IN ACCORDANCE TO CEI EN 60204-1:2006.
– MACHINE ACCORDING TO CE STANDARDS.

- Nominal cutting capacity ( R= 450 N/mm2 ) mm. 4
- Max. cutting capacity ( R= 450 N/mm2 ) mm. 6
- Max. cutting capacity ( R= 700 N/mm2 ) mm. 3
- Cutting length mm. 4050
- Distance between side frames mm. 4150
- Throat mm. 500
- Max. working pressure of the hyd. circuit bar. 240
- Variable rake angle 1° ÷ 2°
- Strokes per minute n. 34 ÷ 40
- Working height ( from floor level ) mm 900
- Back gauge stroke mm 1000
- Oil tank capacity lt. 140
- Max. force of hold down units kN 93
- Main motor power KW 9,2
- Back gauge motor power KW 0,37
- Power supply Volt 400
- Frequency Hz 50
- Approximate weight Kg 11100
- Length “A” mm. 4700
- Width “B” mm. 2000
- Overall of rear barriers “C” mm. 500
- Height “H” mm. 2200
