G-Press GHB25-1250 Hydraulic CNC Pressbrake

GHB 25-1250 Mini Series Press Brake

Innovation from Italian Technology

The GHB 25-1250 mini series press brake is a cutting-edge machine designed for the precise processing of small sheet metal. This machine is particularly well-suited for industries that require high precision, such as those involved in the production of precision instruments and electronic equipment. Here are some key features and technical specifications of the GHB 25-1250:

Key Features:

Compact Structure: The GHB 25-1250 has a small footprint, making it ideal for workshops with limited space. Its compact design also allows for easy relocation using a forklift.

Precision Bending: This press brake is capable of precision bending for small and medium-sized parts, ensuring high-quality results for intricate components.

Technical Specifications:
Bending Force: 250 kN
Bending Length: 1250 mm
Throat Depth: 46 mm
Maximum Stroke: 150 mm
Daylight: 340 mm
Approaching Speed: 220 mm/s
Working Speed: 0-12 mm/s
Return Speed: 200 mm/s
Main Servo Motor Power: 4 kW

This machine’s innovative design and robust specifications make it a valuable asset for any facility focused on precision and efficiency in small sheet metal processing. If you need more detailed information or have specific questions about its operation, feel free to ask!
