GO FAR Single Wall Tank 12,630L

The GO FAR Single Wall Tank range is designed as an economical bulk fuel, lubricants or waste oil tank for Agriculture, Construction and Industrial applications. This innovative yet cost effective single wall tank range is manufactured to the strictest quality standards and meets the design and fabrication requirements of AS1692. The range includes 4,500L | 8,500L | 12,000L | 17,500L Safe Fill Level tanks. For quick deployment we carry these ex stock, subject of course to prior sale.

APPROVALS
Designed and approved to AS1692.

NOTE - to be installed in accordance with AS1940-2017 and State Environmental requirements

TANK DESIGN
Mild Steel Q234B 3mm
Robust Cylindrical Manufacture designed to handle our unique conditions
Heavy Duty Cradle Assembly ready to fasten to a concrete pad
Full under tank visibility for ongoing maintenance inspections
Crane Lifting Lugs

PAINT
White, Two Pack Epoxy Marine Grade

FILL
DN50 (2") Fill Line with Camlock Dust Cap / Non Return Valve / Isolation Valve
Nozzle Fill option with dedicated Fill / Dip Point.
Dip Point with Calibrated Anodised Aluminium Dipstick
Optional Overfill Alarm is available

OUTLET
DN50 (2") Gravity Outlet with Isolation Valve

ACCESS
Galvanised stairway and platform assembly for access to the tank dip point.

VENT
DN50 (2') Galvanised Vent Pipe with Updraft Vent Assembly.
Option for Filtered Breather Assembly

STATUTORY DECALS
supplied with all required Statutory Decals

**Please see Brochure for full Specifications
