GOGOPOWER - CPD20EA - 2T/3000mm Counterbalanced Battery Electric Forklift (4 Point)

?Features

Uses AC motor with high stability of electric control system and low maintenance cost.
LED displays various operating parameters.
Intelligent braking system to ensure safety.
Adjustable steering wheel, seat and safety belt provide a safe and comfortable working environment.
Aviation seats are used, which are comfortable and wear resistant.
Rubber pneumatic tyres are used, which have good shock absorption and comfortable operation.
The gantry adopts a double oil cylinder design, with wide field of vision, high work efficiency and high levels of safety.
It has rubber solid tyres with good wear resistance, safety and stability.
Specifications

Product Model: CPD20EA
Body Type: Four fulcrums of full exchange
Operator Type: Car type
Rated Load Capacity (kg): 2000
Load Centre Distance (mm): 600
Steering Type: Hydraulic
Drive Type: Front axle drive
Travel Speed (Laden/Unladen) (km/h): 8/9
Lifting Speed mm/s (laden/unladen): 230/270
Lowering Speed mm/s (laden/unladen): 210/235
Climbing Ability % (Laden/Unladen): 11/16
Driving Method: Lead acid battery
Braking Type: Drum braking
Driving Motor Power (kW): 6
Pump Motor Power (kW): 5
Lithium Iron Phosphate Battery Voltage/Capacity (V/AH): 48/230
Controller: AC/Curtis
Wheels type: Pneumatic tyre
Lifting Height (mm): 3000
Mast Static Height (mm): 2060
Safety Rack Height (mm): 2150
Seat Height (mm): 1070
Body Length (mm): 2190
Vehicle Width (mm): 1120
Wheel Base (mm): 1356
Ground Clearance (mm): 110
Min Turning Radius (mm): 2030
Forward Tilt Angle: 8 degrees/12 degrees
Fork Size (LxWxT) (mm): 1070x120x40
Front Wheel Size (mm): 6.50-10
Rear Wgeek Size (mm): 5.00-8
Self Weight with Battery (kg): 3000
Warranty

Have peace of mind with Gogopower's Counterbalanced Battery Electric Forklift during the warranty period. We offer Australia wide support on all our Gogopower electric material handling equipment with service contractors nationwide.

12 months warranty.
Battery 6 months
Delivery

We can ship direct to you Australia wide. Alternatively, it can be pick up from either our Smithfield warehouse in NSW or Kenwick warehouse in WA.
