THE BIKE THAT BUILDS CHAMPIONS. With more Supercross and Motocross championships than any other manufacturer, the KX name is synonymous with winning. The KX250 motorcycle represents the KX lineup, built with the sole purpose of dominating the track. Over the past four decades, we've learned what it takes to win and stay on top. Our dedication to building the ultimate machine is undeniable, and the KX250 represents this to the fullest.
2024!!! STOCK IS ON THE WAY
FEATURING:
Uni Trak with adjustable dual-range (high/low-speed) compression damping, adjustable rebound damping and adjustable preload
POWER THROUGH THE FINISH
The powerful 249cc engine features a new friction reduction coating on the piston for increased engine performance.
2024 Models FROM $12,715 PLUS DEALER FEES
Call our sales team today for an awesome package deal
SPECIFICATIONS:
Details
Vehicle Type: Off Road Bike
Bike Type: Motocross
Series: KX
Model Code: KX252CRFNN
Configuration: 249cc, 4-stroke, Liquid-cooled, 4-Valve, DOHC, 1-cyl
LAMS Approved: No
Colours: Lime Green
Country of Origin: JAPAN
Vehicle Class: Motocross 4 Stroke (126 - 250cc)
Engine
Engine Description: 250
Generic Engine Config: Single
Engine Config: Vertical
Engine Capacity: 249
Engine Type: Piston
Engine Stroke: 4
Bore: 78.0
Stroke: 52.2
Cam Type: DOHC (Double Over Head Cam)
Cylinders: 1
Compression Ratio: 14.1:1
Induction System: Aspirated
Carburettor: FI - Fuel Injection; Dual injectors
Throttle Bore: 44
Cooling: Liquid
Lubrication: Semi-Dry Sump; Forced Lubrication
Exhaust Config: 1 Into 1
Exhaust Description: Stainless steel; Header pipe resonator chamber
Start
Ignition: Digital Electronic
Ignition Description: ECU
Starter: Electric
Electrics
Engine Voltage: 12
Charging Method: Alternator & Regulator-Rectifier
Fuel & Emissions
Fuel Type: Petrol
Recommended RON: 95
Fuel Tank Capacity: 6.2
Transmission
Transmission Description: Return
Primary Drive: 3.350 (67/20)
Generic Drive Type: Chain
Final Drive Ratio: 3.846 (50/13)
Generic Gear Type: Manual
Gear Number: 5
Gear Change Method: Left foot lever
1st Gear Ratio: 2.154
2nd Gear Ratio: 1.733
3rd Gear Ratio: 1.438
4th Gear Ratio: 1.235
5th Gear Ratio: 1.045
Clutch Type: Wet, Multi-disc; Hydraulic; Cone disc-spring
Chassis & Suspension
Frame Material: Aluminium
Frame Design: Perimeter
Rake (Caster Angle): 27.10
Trail: 118.0
Handlebar Description: Factory-style ø28.6 mm (1-1/8”) Renthal aluminium Fatba
Side Stand: Not Available
Front Suspension: KYB Inverted fork; Adjustable Compression & Rebound
Front Suspension Travel: 314.0
Rear Suspension: UNI-TRAK Single shock absorber; 19-way (low speed); 4-turns (high speed) compression damping; 22-way rebound damping & adjustable spring preload
Rear Suspension Travel: 316.0
Fork Diameter: 48.0
Swingarm Type: Dual Sided
Swingarm Description: KX450 Swingarm
Brakes
Front Brake Description: Single semi-floating petal disc, Hydraulic
Front Brake Caliper(s): Double Piston
Front Brake Diameter: 270.0
Rear Brake Description: Single petal disc, Hydraulic; Disc srcaper/protector
Rear Brake Caliper(s): Single Piston
Rear Brake Diameter: 240.0
ABS: Not Available
Wheels & Tyres
Wheel Type: Black Alumite rims, Laced-spokes
Wheel Size Front: 21"
Wheel Size Rear: 19"
Rear Tyre: 110/90-19"
Front Tyre: 80/100-21" (51M) Dunlop
Dimensions & Weights
Length: 2190
Width: 820
Height: 1265
Wheelbase: 1485
Ground Clearance: 345.0
Wet / Operational Weight: 108.0
Seat Height: 960
Seating Capacity: 1
Safety & Security
Traction Control: Not Available
Launch Control: Standard
Rider Modes: 3
Convenience
Seating Position: Upright
Adjustable Seat: Not Available
Adjustable Front Footrests: Standard
