Gympie Motorcycles- 2024 KAWASAKI MULE SX (KAF400J) MY23 ATV

BRAND NEW 2023Continuously Variable Transmission (CVT)
2WD/dual-mode with diff. lock
Halogen headlights
22-inch Duro tyres

2WD & 4WD MODELS AVAILABLE READY TO GO
2WD $14,207
4WD $15,500

SPECIFICATIONS:
Details
Vehicle Type: SxS & UTV
Bike Type: ATV
Series: Mule
Model Code: KAF400JPFNN
Configuration: 401cc, 4-stroke, Air-cooled, OHV, 1-cyl
LAMS Approved: No
Colours: Timberline Green
Country of Origin: JAPAN
Vehicle Class: Utility (0 - 500cc)

Engine
Engine Description: 400
Generic Engine Config: Single
Engine Config: Forward-Inclined
Engine Capacity: 401
Engine Type: Piston
Engine Stroke: 4
Bore: 82.0
Stroke: 76.0
Cam Type: OHV (Over Head Valves)
Cylinders: 1
Compression Ratio: 8.3:1
Induction System: Aspirated
Carburettor: Nikki 6C1026
Snorkel Air Intake: Standard
Cooling: Air
Exhaust Config: 1 Into 1
Maximum Power: 9.2
Maximum Power RPM: 3800
Maximum Torque: 27.90
Maximum Torque RPM: 2200

Start
Ignition Description: Magneto & Transistor
Starter: Electric

Electrics
Engine Voltage: 12
Charging Method: Alternator & Regulator-Rectifier
Power Outlet (12V): Standard

Fuel & Emissions
Fuel Type: Petrol
Recommended RON: 91
Fuel Tank Capacity: 16.0

Transmission
Transmission Description: Automatic; Forward/Reverse (Dual mode diff); Belt driven
Generic Drive Type: Direct
Drive Type: Gear
Rear Differential Lock: Standard
Generic Gear Type: Automatic
Gear Type: CVT
Gear Number: 1
Gear Change Method: Gate Type

Chassis & Suspension
Frame Material: Tubular steel
Frame Design: Ladder
Rake (Caster Angle): 9.00
Trail: 40.0
Handlebar Description: Steering wheel; Left hand drive
Skid Plate: Standard
Front Suspension: Independent, MacPherson strut
Front Suspension Travel: 78.0
Rear Suspension: Swingarm; Dual shock absorbers; Adjustable spring preload
Rear Suspension Travel: 79.0
Swingarm Type: Unit Swing

Brakes
Front Brake Description: Dual drums; Hydraulic
Park Brake: Standard
ABS: Not Available

Wheels & Tyres
Wheel Type: Steel
Wheel Size Front: 10"
Rear Tyre: 22x11-10" Tubeless
Front Tyre: 22x9-10" Tubeless

Dimensions & Weights
Length: 2710
Width: 1335
Height: 1780
Ground Clearance: 155.0
Wet / Operational Weight: 439.00
Rear Payload / Carry Weight: 181.0
Seat Height: 765
Seating Capacity: 2
Turning Radius: 3.3
Rear Cargo Bed Length: 1040
Rear Cargo Bed Width: 905
Rear Cargo Bed Depth: 245
Towing Capability: Optional
Trailer Payload: 500

Warranty & Servicing
Warranty in Months from First Registration: 36 Months (3 Years)

Safety & Security
ROPS Approved: Standard

Convenience
Seat Description: Bench type
Glove Box(s): Standard
Roof: Optional

System
Import Percent: 100
Import Part Percent: 80
WU Category: 3
