MODEL
HALO8-K
SINGLE PHASE
PRIME RATING
8/8 kW/kVA
ENGINE
KUBOTA 722
FUEL TANK
28 L
STANDBY RATING(AMPS)
33
STANDBY RATING(kW/kVA)
9/9
ALTERNATOR
SINCRO EK2LCA
FUEL CONSUMPTION (L/h)
2.4
TECHNICAL DATA
Specifications
VIKING MODEL: HALO8-K
VIKING MODEL: KUBOTA 722
ALTERNATOR: SINCRO EK2LCA
STANDBY AMPS: 33A
STANDBY RATING(AMPS) (KW/KVA): 9kW/9kVA
PRIME RATING (KW/KVA): 8kW/8kVA
CONTINUOUS POWER (COP): 6kW/6kVA
DIMENSIONS AND WEIGHT
LENGTH (MM): 1,360MM
WIDTH (MM): 690MM
HEIGHT (MM): 895MM
WEIGHT (KG): 560KG
FUEL SYSTEM
FUEL TANK CAPACITY: 28L
PRIME FUEL CONSUMPTION 100%: 2.8L/H
PRIME FUEL CONSUMPTION 75%: 2.4L/H
PRIME FUEL CONSUMPTION 50%: 1.9L/H
