FIVE-AXIS ADJUSTABLE SELF-CENTERING VISE (ASC-S)

MODEL:ASC-77X102S, 77X130S, 77X170S, 77X210S, 127X160S, 127X210S, 127X260S, 127X310S, 127X360S

-Significantly upgrade CNC 5-Axis Machines
-Special 45° dovetail structure with teeth
-The patented calibration system can regulate clamping centre easily and rapidly

Features:

-Vice body is made of High quality Steel (S50C) and its slideways gone through high-frequency hardening to achieve HRC50, which makes the whole part durable.
-Detachable jaws are made of High quality Tool Steel (SCM440) and gone through carburizing to achieve HRC55. Since both sides are fixed size and able to be used as a datum, users can reverse them to increase clamping range.
-The vice's clamping force can achieve 1300KG, the repeatability positioning precision of its clamping centre is within 0.015mm.
-Users can calibrate the clamping centre of vice by adjusting the screws on both ends.
-The 45° dovetail structure with teeth on the upper jaw ensures the bottom of the workpiece to be firmly clamped.

Delahenty Machinery sell a wide range of HOMGE milling accessories.
