Husqvarna Double Drum Padfoot Roller | Model: LP 9505

The highly productive Husqvarna LP 9505 articulated trench compactor delivers a smooth, compacted surface, which doesn't dig up soil when turning. Due to the high operating weight and ultimate traction, it is suitable for all kinds of soils (dry or wet) but especially suited for cohesive materials like clay and silt. The fuel-efficient engine provides class-leading power for a whole day of uninterrupted work and the radio remote control offers great flexibility, better ergonomics and safer working conditions. Servicing is quick and easy with all service points clearly marked and easily accessed under the hoods.

Technical Data

Engine
Motor/engine model - D1105
Power output - 18 kW
Exhaust emissions (CO2 EU V) - 976 g/kWh
Power/fuel type - Diesel

Specifications
Frequency - 42 Hz
Speed forward max - 1.35 km/h
Speed - 22.5 m/min
Starter - Electric

Dimensions
Weight - 1,680 kg
Length - 1,856 mm
Width - 850 mm
Height - 1,369 mm

Sound and noise
Sound power level, guaranteed (LWA) - 106 dB(A)
Sound pressure level at operators ear - 83 dB(A)
